What is Stainless Steel Profile?
Stainless steel profiles are metal products that are preferred in many industrial and architectural fields thanks to their aesthetic appearance and high durability. They are usually made of stainless steel and are available in different cross-sections such as square, rectangular, or round.
KALINLIK (MM) | ||||||||||
DIŞ ÇAP (MM) | 1.00 | 1.20 | 1.50 | 2.00 | 2.50 | 3.00 | 4.00 | 5.00 | 6.00 | |
20*10 | 0.453 | 0.538 | 0.661 | – | – | – | – | – | – | |
20*15 | 0.553 | 0.634 | 0.781 | 1.016 | – | – | – | – | – | |
25*10 | 0.553 | 0.634 | 0.781 | 1.016 | – | – | – | – | – | |
25*15 | 0.613 | 0.729 | 0.900 | 1.176 | – | – | – | – | – | |
30*10 | 0.613 | 0.729 | 0.900 | 1.176 | – | – | – | – | – | |
30*15 | 0.693 | 0.825 | 1.020 | 1.335 | – | – | – | – | – | |
30*20 | 0.772 | 0.921 | 1.140 | 1.495 | – | – | – | – | – | |
35*15 | 0.772 | 0.922 | 1.140 | 1.495 | – | – | – | – | – | |
35*20 | 0.852 | 1.017 | 1.259 | 1.654 | – | – | – | – | – | |
40*10 | – | – | 1.140 | 1.495 | – | – | – | – | – | |
40*15 | 0.852 | 1.017 | 1.259 | 1.654 | – | – | – | – | – | |
40*20 | 0.932 | 1.112 | 1.379 | 1.813 | 2.236 | 2.645 | – | – | – | |
40*30 | 1.091 | 1.303 | 1.618 | 2.132 | 2.635 | 3.124 | – | – | – | |
50*10 | 0.932 | 1.112 | 1.379 | 1.813 | – | 2.645 | – | – | – | |
50*20 | 1.091 | 1.303 | 1.618 | 2.132 | – | – | – | – | – | |
50*25 | – | 1.399 | 1.738 | 2.292 | – | – | – | – | – | |
50*30 | 1.251 | 1.495 | 1.857 | 2.451 | 3.033 | 3.602 | 4.703 | – | – | |
50*40 | – | 1.686 | 2.097 | 2.770 | 3.432 | 4.081 | 5.309 | – | – | |
60*20 | 1.251 | 1.495 | 1.857 | 2.451 | 3.033 | 3.602 | 4.703 | – | – | |
60*30 | – | 1.686 | 2.097 | 2.770 | 3.432 | 4.081 | 5.309 | – | – | |
60*40 | – | 1.878 | 2.336 | 3.089 | 3.831 | 4.559 | 5.960 | – | – | |
70*20 | – | – | 2,097 | 2.770 | 3.432 | 4.081 | 5.309 | – | – | |
70*30 | – | – | 2.336 | 3.089 | – | 4.559 | 5.960 | – | – | |
70*40 | – | – | 2.575 | 3.409 | 4.229 | 5.038 | – | – | – | |
80*20 | – | – | 2.336 | 3.089 | – | – | – | – | – | |
80*40 | – | 2.261 | 2.814 | 3.727 | 4.628 | 5.516 | 7.225 | 8,943 | – | |
80*60 | – | – | 3.293 | 4.365 | 5.426 | 6.473 | 8.531 | 10.538 | – | |
100*40 | – | – | 3.293 | 4.365 | 5.426 | 6.473 | 8.531 | 10.538 | – | |
100*50 | – | – | 3.532 | 4.684 | 5.824 | 6,952 | 9,169 | 11,335 | ||
100*60 | – | – | 3.771 | 5.003 | 6.223 | 7.430 | 9,807 | 12,133 | 14.410 | |
100*80 | – | – | 4.250 | 5,642 | 7.021 | 8,387 | 11,083 | 13,728 | 16,324 | |
120*40 | – | – | 3.771 | 5,003 | 6,223 | 7,430 | 9,807 | 12,133 | 14.410 | |
120*60 | – | – | 4.250 | 5,642 | 7,021 | 8,387 | 11,083 | 13,728 | 16,324 | |
120*80 | – | – | 4.728 | 6,279 | 7,818 | 9,343 | 12,358 | 15,332 | 18,336 | |
140*60 | – | – | – | 6,279 | – | 9,343 | 12,358 | – | – | |
150*50 | – | – | – | 6,279 | – | 9,343 | 12,358 | 15,332 | 18,336 | |
150*100 | – | – | – | 7,874 | – | 11,735 | 15.548 | – | – | |
160*80 | – | – | – | 7.555 | – | 11.258 | 14.910 | – | – | |
180*60 | – | – | – | 7.555 | – | 11.258 | 14.910 | – | – |
Definition of Stainless Profile
A stainless steel profile is a bar-shaped metal material manufactured from corrosion-resistant steel and available in various sizes and shapes. These profiles are used to provide structural support, mechanical strength, or for decorative purposes.
Areas of Use
Due to their durability, hygiene, and aesthetic properties, stainless steel profiles are used in a wide range of industries, from construction to the automotive industry, from the food industry to the chemical industry. Their resistance to outdoor conditions, in particular, provides a long-lasting solution.
Stainless Steel Profile Types and Technical Specifications
Stainless Profile Types
Do profile
Features:
This profile type, with 90-degree corners and equal edges, stands out with its mechanical durability.
Areas of Use:
It is mostly preferred in carrier systems, railings and decorative structures.
Rectangular Profile
Advantages:
It provides high carrying capacity with different aspect ratios. It is suitable for both horizontal and vertical use.
Round Profile
Technical Details:
It is widely used in fluid handling systems, railings, and aesthetic solutions. It has high weldability.
Special Size Profiles
Profiles produced specifically for the project are preferred in architectural applications or special production lines.
Stainless Profile Production Process
Raw Material Selection
The first step in producing a quality stainless steel profile is to choose the right type of stainless steel (e.g. 304, 316).
Production Stages
Steel is shaped by cold or hot rolling methods, then cut and its surface is processed after being shaped in special machines.
Quality Control Process
Mechanical and chemical tests are applied to each production batch. Quality is assured through certifications such as ISO 9001.
Why Choose Stainless Steel Profile?
Corrosion Resistance
The biggest advantage of stainless profiles is their high resistance to moisture, rain and chemicals.
Long-Lasting Use
Since there are no problems such as surface deterioration, decay or rust, maintenance costs are reduced and the service life is increased.
Aesthetic Appearance
Its bright and clean surface, which is frequently preferred in modern architecture, adds elegance to projects.
Hygienic Structure
It is frequently used in the food and pharmaceutical industries because it is easy to clean and does not harbor bacteria.
Stainless Profile Usage Areas
Construction Industry
Stainless steel profiles are frequently used in carrier systems, suspended ceilings and facade cladding.
Food and Beverage Industry
In this sector where hygiene is critical, it is indispensable in production lines and transportation systems.
Chemical and Pharmaceutical Industry
With its chemical-resistant structure, it can be used safely in laboratory equipment.
Furniture and Decoration
Stainless steel profiles, which are the ideal material for modern and simple designs, provide an aesthetic appearance in interior spaces.
Automotive and Machinery Industry
It stands out with its durability in chassis, protection systems and special machine parts.
What to Consider When Choosing a Stainless Steel Profile?
Quality Certificates and Documents
It is important for reliability that products are supported by documents such as TSE and ISO.
Material Quality (304, 316, etc.)
304 grade is for general use, while 316 is more resistant to seawater and chemicals.
Thickness and Dimensions
Determining the appropriate thickness and dimensions for the intended use directly affects performance.
Stainless profileWith its advantages like longevity, aesthetics, hygiene, and durability, it makes life easier in almost every sector. If you’re looking for a high-quality, affordable stainless steel profile suitable for your project, asinoks.com is the right place. Enjoy secure shopping and expert support!
Stainless steel profiles can be used for many years thanks to their durable structure. Their resistance to corrosion extends their service life.
Stainless steel profiles should be maintained through regular cleaning and inspection. They are easy to clean thanks to their hygienic surfaces.
The prices of stainless steel profiles are determined based on the size of the profile, material quality, and special requirements. ASİNOKS aims to offer its customers the most economical solutions.
Stainless steel profiles offer many advantages, including durability, hygiene, corrosion resistance, and aesthetic appeal. They are preferred in many industries due to their wide range of applications.
